DescriptionCreate a cleaner home-theatre installation by mounting Sonos Arc or Arc Ultra directly beneath the TV. Select the correct soundbar option and follow Sonos clearance guidance so the upward- and side-firing drivers remain unobstructed.Why it stands outTwo model selectionsChoose the dedicated Arc or Arc Ultra option shown in the variants.Acoustic clearancePurpose-built placement helps preserve space around the soundbar’s directional drivers.Low-profile lookPositions the soundbar close to the wall without using a media console.Cable accessPower, HDMI and network connections remain reachable.Best for
Sonos Arc or Arc Ultra
Wall-mounted televisions
Dolby Atmos rooms
Minimal media-console setups
Permanent home-theatre installations
Not ideal for
Sonos Beam or Ray
TV mounts that need the soundbar to move with the screen
Installations with obstructed soundbar ends
Walls unsuitable for the required load
EMiUZEK Buying Notes
Select Arc Wall Mount or Arc Ultra Wall Mount; verify the exact product before ordering.
Soundbar is not included.
For Arc Ultra, Sonos recommends at least 4 in / 10 cm between the soundbar and TV and 1 ft / 30 cm from each end to an obstruction.
FAQDoes the Arc mount fit Arc Ultra?Sonos states Arc Ultra is compatible with the Sonos Arc Wall Mount, but choose the listed model option that best matches your installation.Is the soundbar included?No. This listing is for the selected wall mount.How much clearance does Arc Ultra need?Sonos recommends at least 4 in / 10 cm from the TV and 1 ft / 30 cm from each end to walls or obstructions.Can it be installed above a TV?Sonos permits above-TV installation, though below-TV placement is recommended.Does it attach to a moving TV mount?No. A direct wall bracket remains fixed; choose a TV-mount soundbar bracket if synchronized movement is required.Can I hide the cables?Plan an approved in-wall or surface cable route before installation; do not place the power cord inside a wall unless locally permitted.Will wall mounting change the sound?Correct clearance is essential; run Trueplay after changing placement.What wall hardware should I use?Use fixings appropriate to wood stud, drywall, plaster, concrete or brick as applicable.HOW TO CONNECT
Plan clearance — Centre the soundbar and mark the bracket while maintaining the required TV and side clearances.
Secure bracket — Drill and install wall-specific anchors or stud fixings, then level the bracket.
Attach and connect — Mount Arc or Arc Ultra, connect power and HDMI eARC/ARC, then run Sonos setup and Trueplay.
Technical Specifications
Feature
Specification
Compatible products
Sonos Arc or Sonos Arc Ultra, according to selected variant
Product type
Fixed soundbar wall mount
Soundbar included
No
Recommended position
Below TV; above TV also supported
Arc Ultra TV clearance
Minimum 4 in / 10 cm
Arc Ultra end clearance
Minimum 1 ft / 30 cm from each end to obstruction
Controls orientation
Facing upward
Connections retained
Power, HDMI eARC/ARC, Ethernet
Installation surfaces
Depends on wall-specific fixings
Adjustment
Fixed after installation
Use
Indoor
Additional Product Content
DescriptionBring a permanently installed passive stereo system to a patio, garden or covered outdoor area. These Sonos Architectural speakers by Sonance combine an IP66 enclosure with an 8-ohm load and are optimized for use with Sonos Amp.Why it stands outIP66 outdoor constructionBuilt for dust, water, humidity, salt spray, heat, UV exposure and freezing conditions.Purpose-built acoustic designA pivoting high-excursion woofer and one-inch tweeter cover 55 Hz–20 kHz.Sonos Amp optimizationThe Sonos app can apply dedicated DSP when the speakers are used with Sonos Amp.Installation-ready pairGrilles, FastMount brackets and terminal covers support a permanent outdoor setup.Best for
Patios and gardens
Covered outdoor entertaining areas
Permanent wired outdoor audio
Sonos Amp systems
Stereo outdoor zones
Not ideal for
Portable or battery-powered use
Direct connection to phones or Wi-Fi without an amplifier
Sub-bass-focused systems without a subwoofer
Installations without weather-rated speaker cable and safe routing
EMiUZEK Buying Notes
These are passive speakers and require an amplifier; Sonos Amp is the recommended match.
Use 16 AWG or larger outdoor-rated speaker cable and weather-safe routing.
The 5–130 W figure is power handling, not built-in amplifier output.
FAQAre these wireless speakers?No. They are passive speakers and require speaker cable connected to an amplifier.Are they waterproof?They are IP66 weatherproof and dustproof, but should still be installed according to the outdoor installation guide.What amplifier should I use?They are optimized for Sonos Amp; another suitable amplifier must support an 8-ohm load and appropriate power.Can one Sonos Amp power multiple pairs?Follow Sonos Amp impedance and architectural-speaker guidance; do not combine loads without checking the total impedance.What is the frequency response?Sonos lists 55 Hz–20 kHz at ±3 dB.Are mounting brackets included?Sonos lists a pair of FastMount brackets, grilles and wiring-terminal covers with the speaker pair.Can they stay outdoors in winter?The official operating specification covers -13°F to 149°F / -25°C to 65°C when properly installed.Do they support Trueplay?With Sonos Amp, Optimize Sonos Speakers applies dedicated tuning; Trueplay availability depends on the supported architectural setup.HOW TO CONNECT
Wire to amplifier — Run 16 AWG or larger outdoor-rated speaker cable from each speaker to a suitable amplifier.
Mount and seal — Install the FastMount brackets, secure each speaker and fit the terminal covers.
Optimize in Sonos — When used with Sonos Amp, select the matching Sonos Architectural speaker type in the app.
Technical Specifications
Feature
Specification
Product type
Passive outdoor speakers, pair
Design partner
Sonance
Woofer
One high-excursion pivoting woofer per speaker
Tweeter
One-inch tweeter per speaker
Frequency response
55 Hz–20 kHz (±3 dB)
Nominal impedance
8 ohms
Sensitivity
89 dB SPL (2.83 V / 1 m)
Power handling
5 W minimum; 130 W maximum
Weather rating
IP66; Mil Spec 810 environmental conformity
Temperature range
-13°F to 149°F / -25°C to 65°C
Dimensions each
12.96 × 7.52 × 7.83 in / 329.2 × 191 × 199 mm
Weight each
8.82 lb / 4 kg
Colours
Black; white
Finish
Matte
Required amplifier
Suitable external amplifier; optimized for Sonos Amp
Recommended cable
16 AWG or larger speaker wire
Additional Product ContentComparison: choose the right product
Decision point
Sonos Outdoor by Sonance
Bowers & Wilkins AM-1
System type
Passive installed pair
Passive installed outdoor speakers
Weather protection
IP66; Mil Spec 810 environmental conformity
Weather-resistant design
Nominal impedance
8 ohms
8 ohms
Best when
You want Sonos Amp optimization and IP66 specification
You prefer Bowers & Wilkins voicing
DescriptionFill a larger room with full-range wireless sound from Sonos Five. Six Class-D amplifiers drive three tweeters and three midwoofers, while 3.5 mm line-in connects a preamplified turntable, CD player or computer to the Sonos multiroom system.Why it stands outSix-driver acoustic systemThree tweeters and three midwoofers deliver wide stereo detail and substantial bass.Useful analogue line-inBring a turntable with phono stage, CD player or computer into Sonos.Orientation-aware soundHorizontal placement creates stereo from one unit; vertical placement supports focused mono or a stereo pair.Trueplay room tuningSupported iOS devices optimize response for the final placement.Best for
Large-room music
Turntables with phono preamp
Stereo pairs
Sonos multiroom homes
Listeners prioritizing bass without a subwoofer
Not ideal for
Bluetooth playback
Voice-assistant control built into the speaker
Dolby Atmos spatial music
Battery-powered portable use
EMiUZEK Buying Notes
Five does not list Bluetooth audio or built-in voice microphones.
A turntable requires a built-in or external phono preamp.
Stereo pairing requires two matching Sonos Five speakers.
FAQDoes Five support Bluetooth?No Bluetooth audio input is listed; use WiFi, AirPlay 2, Ethernet or line-in.Can I connect a turntable?Yes, through 3.5 mm line-in when the turntable has a phono preamp.Does one Five play stereo?Horizontally, one Five separates left and right channels; two vertically placed Fives create a wider dedicated stereo pair.Does it support Trueplay?Yes, with a supported iOS device.Can it be used as a surround?A pair of Five speakers can be used as surrounds with supported Sonos home-theatre products.Does it have voice control?Five does not include the far-field voice microphones found on some Sonos smart speakers.Can I hardwire it?Yes. It has a 10/100 Ethernet port.Is it humidity resistant?Yes, for indoor high-humidity spaces; it is not weatherproof.HOW TO CONNECT
WiFi or Ethernet — Add Five in the Sonos app over WiFi or connect the 10/100 Ethernet port.
Apple AirPlay 2 — Select Five from the AirPlay menu on a compatible Apple device.
3.5 mm line-in — Connect a line-level source and configure autoplay or source level in the Sonos app.
Technical Specifications
Feature
Specification
Amplifiers
Six Class-D digital
Tweeters
Three
Midwoofers
Three
Cabinet
Sealed architecture
Line input
3.5 mm analogue
WiFi
802.11a/b/g/n, 2.4 or 5 GHz
Ethernet
10/100
AirPlay
Apple AirPlay 2
Bluetooth
Not supported
Trueplay
Supported iOS device required
Dimensions
203 × 364 × 154 mm
Weight
6.3 kg
Power
100–240 V, 50/60 Hz
CPU
Quad-core 1.3 GHz
Colours
Black; white
Orientation
Horizontal stereo; vertical mono/stereo-pair use
Additional Product ContentComparison: choose the right product
Decision point
Sonos Five
Sonos Era 300
Primary strength
Powerful conventional stereo and analogue line-in
Dolby Atmos spatial audio
Bluetooth
No
Bluetooth 5.3
Analogue input
Built-in 3.5 mm
USB-C adapter required
Best when
You prioritize full-range stereo and turntable/CD input
You prioritize spatial music and Atmos surrounds
Description
FiiO FT5 is a premium open-back planar magnetic headphone designed for audiophiles seeking high resolution, wide soundstage, and natural musical reproduction.
Featuring a large planar magnetic driver, ultra-thin diaphragm, and open-back acoustic design, FT5 delivers detailed and immersive sound for advanced desktop HiFi systems.
Why it stands out
Large Planar Magnetic Driver
FT5 uses a large planar magnetic driver with an ultra-thin diaphragm to deliver fast response, high resolution, and accurate sound reproduction.
Open-Back Audiophile Sound
The open-back design creates a spacious and natural listening experience with a wide soundstage and excellent instrument separation.
High-Resolution Music Performance
FT5 reveals fine details while maintaining smooth and natural musical expression across different genres.
Premium Desktop HiFi Experience
Designed for advanced headphone systems, FT5 pairs well with high-quality DACs and headphone amplifiers.
Best for
High-end desktop HiFi systems
Audiophile music listening
DAC and headphone amplifier setups
Classical, jazz, vocal, and instrumental music
Users seeking wide soundstage headphones
Not ideal for
Users needing noise isolation
Users looking for wireless headphones
Users wanting portable everyday headphones
Users without suitable audio equipment
EMiUZEK Buying Notes
FiiO FT5 is an open-back planar magnetic headphone, not a wireless headphone.
The open-back design provides a wider soundstage but allows sound leakage.
A quality DAC and headphone amplifier are recommended to achieve the best performance.
It is designed mainly for home listening environments.
FAQ
Is FiiO FT5 a planar magnetic headphone?
Yes.
FT5 uses a large planar magnetic driver designed for high-resolution audio reproduction.
Does FiiO FT5 require a headphone amplifier?
It can work with compatible devices, but a powerful DAC/headphone amplifier can help achieve better dynamics and control.
Is FiiO FT5 suitable for portable players?
Yes, but it performs best with powerful portable players or desktop DAC/amps.
Does FiiO FT5 block outside noise?
No.
The open-back design prioritizes soundstage and natural sound over isolation.
What is the difference between FT5 and FT1 Pro?
FT5 is positioned as a higher-end planar magnetic headphone with improved performance, while FT1 Pro focuses on providing affordable planar magnetic performance.
Does FiiO FT5 support balanced connection?
Yes.
It supports balanced connection through compatible 4.4mm cables.
HOW TO CONNECT
Desktop HiFi Setup
Source icon: ComputerSource: High Resolution MusicConnection: USB DACOutput connection: 4.4mm Balanced / 3.5mmTarget icon: FiiO FT5Output: High-End Headphone System
Note: Pair with a quality DAC and headphone amplifier for maximum performance.
Portable HiFi Setup
Source icon: Portable Music PlayerSource: Lossless MusicConnection: 4.4mm Balanced OutputTarget icon: FiiO FT5Output: Portable Audiophile System
Note: Use powerful portable devices for optimal driving performance.
Technical Specifications
Headphone
Product Type: Open-Back Planar Magnetic Headphone
Driver Type: Planar Magnetic
Driver Size: 90mm
Diaphragm Thickness: 1μm
Design: Open-Back
Audio Performance
Frequency Response: 7Hz–40kHz
Impedance: 36Ω
Sensitivity: 110dB
Maximum Input Power: 2000mW
Connectivity
Cable Connection: Detachable
Connector: Dual 3.5mm
Plug Options: 3.5mm / 4.4mm
Balanced Connection: Supported
General
Weight: Approx. 456g
Wearing Style: Over-Ear
Application: Home HiFi Listening
Recommended System Setup
Setup
Connection
Desktop System
Computer → DAC → Headphone Amplifier → FT5
Balanced System
DAC/Amp 4.4mm Output → FT5
Portable System
HiFi Player → FT5
What's in the box
FiiO FT5 Headphones ×1
Balanced Cable ×1
Single-Ended Cable ×1
Carrying Case ×1
Adapter ×1
User Manual ×1
Download Center
Access product manuals, technical documents, and support resources.
https://emiuzek.com/pages/download
Additional Product Content
FiiO Planar Headphone Comparison
Feature
FT5
FT1 Pro
Product Position
High-End Planar Magnetic Headphone
Affordable Planar Magnetic Headphone
Driver Type
Planar Magnetic
Planar Magnetic
Design
Open-Back
Open-Back
Sound Focus
Resolution, dynamics, soundstage
High-value planar performance
Best Use
Advanced desktop HiFi
Entry planar HiFi
Description
FiiO FT13 is a premium closed-back wooden HiFi headphone designed for listeners seeking detailed sound, natural timbre, and a refined listening experience.
Featuring a large 60mm dynamic driver, natural wood ear cups, and a high-performance diaphragm design, FT13 delivers immersive sound for desktop and portable HiFi systems.
Why it stands out
Natural Wooden Acoustic Design
FT13 uses carefully selected wooden ear cups to provide a premium appearance and help create a natural, musical listening experience.
Large Dynamic Driver Performance
The 60mm dynamic driver delivers powerful bass, detailed mids, and smooth high-frequency reproduction across different music genres.
High-Resolution Musical Sound
The advanced diaphragm design provides accurate detail retrieval while maintaining a natural and enjoyable sound character.
Comfortable Long Listening Experience
The over-ear closed-back structure and ergonomic design provide comfortable listening for extended music sessions.
Best for
Desktop HiFi headphone systems
Music enthusiasts seeking premium sound
Vocal, jazz, classical, and acoustic music
Users upgrading from entry-level headphones
DAC and headphone amplifier setups
Not ideal for
Users looking for wireless headphones
Users needing active noise cancellation
Users wanting a lightweight portable headphone
Users requiring professional studio monitoring
EMiUZEK Buying Notes
FiiO FT13 is a wired HiFi headphone, not a wireless model.
It uses a closed-back design and is suitable for personal listening environments.
A quality DAC or headphone amplifier can help achieve better performance.
Please select the correct cable version before purchase.
FAQ
Is FiiO FT13 a wireless headphone?
No.
FT13 is a wired HiFi headphone designed for high-quality audio playback.
What driver does FiiO FT13 use?
FT13 uses a large 60mm dynamic driver with a high-performance diaphragm.
Does FiiO FT13 require a headphone amplifier?
It can work with many audio devices, but pairing with a quality DAC and headphone amplifier can improve performance.
Is FiiO FT13 suitable for portable players?
Yes.
It can be used with compatible portable music players and DAC/amps.
What makes the wooden ear cups special?
The wooden ear cups provide a premium appearance and contribute to a more natural acoustic character.
What is the difference between FT13 and FT1?
FT13 is positioned as a higher-level wooden HiFi headphone with upgraded materials and tuning compared with FT1.
HOW TO CONNECT
Desktop HiFi Setup
Source icon: ComputerSource: High Resolution MusicConnection: USB DAC / Headphone AmplifierOutput connection: Headphone OutputTarget icon: FiiO FT13Output: Desktop HiFi Listening
Note: Pair with a DAC and amplifier for the best performance.
Portable Player Setup
Source icon: Portable PlayerSource: Local Music FilesConnection: Headphone OutputTarget icon: FiiO FT13Output: Portable HiFi System
Note: Enjoy high-quality wired music playback.
Technical Specifications
Headphone
Product Type: Closed-Back Wooden Dynamic Headphone
Driver Type: Dynamic Driver
Driver Size: 60mm
Diaphragm: High-performance Composite Diaphragm
Ear Cup Material: Natural Wood
Audio Performance
Frequency Response: 7Hz–40kHz
Impedance: 32Ω
Sensitivity: Approx. 110dB
Wearing Style: Over-Ear
Connectivity
Cable Connection: Detachable
Connector: Dual 3.5mm
Plug Options: 3.5mm / 4.4mm
General
Weight: Approx. 380g
Design: Closed-Back
Application: Home HiFi / Portable Audio
Recommended System Setup
Setup
Connection
Portable System
Player → FT13
Desktop System
Computer → DAC → Headphone Amplifier → FT13
Balanced System
DAC/Amp 4.4mm Output → FT13
What's in the box
FiiO FT13 Headphones ×1
Detachable Cable ×1
Carrying Case ×1
Adapter ×1
User Manual ×1
Download Center
Access product manuals, technical documents, and support resources.
https://emiuzek.com/pages/download
Additional Product Content
FiiO FT Series Comparison
Feature
FT13
FT1
FT1 Pro
Product Type
Premium Wooden Dynamic Headphone
Closed-Back Dynamic Headphone
Open-Back Planar Headphone
Driver Type
Dynamic
Dynamic
Planar Magnetic
Design
Closed-Back Wooden
Closed-Back
Open-Back
Main Focus
Premium materials and musical sound
Balanced everyday HiFi
Detail and wide soundstage
Best Use
High-quality home listening
Daily HiFi listening
Audiophile desktop listening
Description
SNOWSKY ECHO is a compact high-resolution portable music player designed for users who enjoy a simple and dedicated music experience.
With dual headphone outputs, Bluetooth connectivity, USB DAC functionality, and microSD expansion, ECHO combines retro-inspired design with modern portable HiFi features.
Why it stands out
Dedicated Music Experience
ECHO focuses on pure music playback without unnecessary smartphone distractions, giving users a simple and focused listening experience.
High-Resolution Portable Audio
Supports lossless music playback with high-quality decoding capability for detailed and natural sound performance.
Dual Headphone Connections
The 3.5mm single-ended and 4.4mm balanced outputs provide flexible compatibility with different headphones and earphones.
Retro Design with Modern Features
Combines a nostalgic music player design with modern functions including Bluetooth, USB DAC, and customizable EQ.
Best for
Portable HiFi listening
IEM and headphone users
Local music library playback
Travel and commuting
Users wanting a distraction-free music player
Not ideal for
Users needing Spotify or streaming apps
Users looking for Android-based smart players
Users needing powerful desktop headphone amplification
Users wanting a network streamer
EMiUZEK Buying Notes
SNOWSKY ECHO is a portable music player, not a smartphone-based streaming device.
It is designed mainly for local music playback through microSD storage.
It can also work as a USB DAC when connected to compatible computers or devices.
Performance depends on the connected headphones or earphones.
FAQ
Does SNOWSKY ECHO support Bluetooth?
Yes.
It supports Bluetooth connectivity for wireless audio functions and compatible devices.
Can SNOWSKY ECHO play music without a smartphone?
Yes.
ECHO is designed as a standalone music player using local music files stored on supported memory cards.
Does SNOWSKY ECHO support microSD cards?
Yes.
It supports expandable storage through a microSD card for storing music files.
Does SNOWSKY ECHO support balanced headphones?
Yes.
It includes a 4.4mm balanced headphone output in addition to the 3.5mm single-ended output.
Can SNOWSKY ECHO be used as a USB DAC?
Yes.
It can connect to computers and compatible devices as a USB DAC.
Does SNOWSKY ECHO support streaming apps like Spotify?
No.
ECHO is designed as a dedicated local music player rather than an Android streaming player.
What headphones work best with SNOWSKY ECHO?
It works well with IEMs, portable headphones, and efficient headphones suitable for portable devices.
HOW TO CONNECT
Portable Music Setup
Source icon: microSD CardSource: Local Music FilesConnection: Internal PlaybackOutput connection: 3.5mm / 4.4mm Headphone OutputTarget icon: Headphones / IEMsOutput: Portable HiFi Listening
Note: Enjoy dedicated music playback anywhere.
Wireless Audio Setup
Source icon: SNOWSKY ECHOSource: Local Music LibraryConnection: BluetoothTarget icon: Bluetooth DeviceOutput: Wireless Audio System
Note: Connect with compatible Bluetooth devices.
USB DAC Setup
Source icon: ComputerSource: Digital MusicConnection: USBOutput connection: Headphone OutputTarget icon: HeadphonesOutput: USB DAC Audio System
Note: Use ECHO as an external audio device.
Technical Specifications
Audio
Feature
Specification
Product Type
Portable High-Resolution Music Player
DAC
High-Performance DAC System
Audio Playback
Lossless Music Playback
EQ
Supported
Outputs
Feature
Specification
3.5mm Output
Supported
4.4mm Balanced Output
Supported
USB DAC Output
Supported
Storage & Connectivity
Feature
Specification
microSD Expansion
Supported
Bluetooth
Supported
USB-C
Supported
Firmware Update
Supported
General
Feature
Specification
Product Type
Portable Music Player
Display
Color Display
Battery
Built-in Rechargeable Battery
Recommended System Setup
Setup
Connection
IEM Listening
ECHO → IEM
Portable Headphone
ECHO → Headphones
USB DAC Mode
Computer → ECHO → Headphones
Bluetooth System
ECHO → Wireless Device
What's in the box
SNOWSKY ECHO ×1
USB-C Cable ×1
Protective Accessories ×1
User Manual ×1
Download Center
Access product manuals, technical documents, and support resources.
https://emiuzek.com/pages/download
Additional Product Content
SNOWSKY Portable Player Comparison
Feature
ECHO
ECHO MINI
Product Position
Portable HiFi Music Player
Compact Entry-Level Music Player
Main Focus
Higher-performance portable audio
Small retro music player
Balanced Output
Yes
Yes
USB DAC
Yes
Yes
microSD Expansion
Yes
Yes
Best Focus
Portable HiFi enthusiasts
Simple everyday music playback
Description
SNOWSKY ECHO is a compact high-resolution portable music player designed for users who enjoy a simple and dedicated music experience.
With dual headphone outputs, Bluetooth connectivity, USB DAC functionality, and microSD expansion, ECHO combines retro-inspired design with modern portable HiFi features.
Why it stands out
Dedicated Music Experience
ECHO focuses on pure music playback without unnecessary smartphone distractions, giving users a simple and focused listening experience.
High-Resolution Portable Audio
Supports lossless music playback with high-quality decoding capability for detailed and natural sound performance.
Dual Headphone Connections
The 3.5mm single-ended and 4.4mm balanced outputs provide flexible compatibility with different headphones and earphones.
Retro Design with Modern Features
Combines a nostalgic music player design with modern functions including Bluetooth, USB DAC, and customizable EQ.
Best for
Portable HiFi listening
IEM and headphone users
Local music library playback
Travel and commuting
Users wanting a distraction-free music player
Not ideal for
Users needing Spotify or streaming apps
Users looking for Android-based smart players
Users needing powerful desktop headphone amplification
Users wanting a network streamer
EMiUZEK Buying Notes
SNOWSKY ECHO is a portable music player, not a smartphone-based streaming device.
It is designed mainly for local music playback through microSD storage.
It can also work as a USB DAC when connected to compatible computers or devices.
Performance depends on the connected headphones or earphones.
FAQ
Does SNOWSKY ECHO support Bluetooth?
Yes.
It supports Bluetooth connectivity for wireless audio functions and compatible devices.
Can SNOWSKY ECHO play music without a smartphone?
Yes.
ECHO is designed as a standalone music player using local music files stored on supported memory cards.
Does SNOWSKY ECHO support microSD cards?
Yes.
It supports expandable storage through a microSD card for storing music files.
Does SNOWSKY ECHO support balanced headphones?
Yes.
It includes a 4.4mm balanced headphone output in addition to the 3.5mm single-ended output.
Can SNOWSKY ECHO be used as a USB DAC?
Yes.
It can connect to computers and compatible devices as a USB DAC.
Does SNOWSKY ECHO support streaming apps like Spotify?
No.
ECHO is designed as a dedicated local music player rather than an Android streaming player.
What headphones work best with SNOWSKY ECHO?
It works well with IEMs, portable headphones, and efficient headphones suitable for portable devices.
HOW TO CONNECT
Portable Music Setup
Source icon: microSD CardSource: Local Music FilesConnection: Internal PlaybackOutput connection: 3.5mm / 4.4mm Headphone OutputTarget icon: Headphones / IEMsOutput: Portable HiFi Listening
Note: Enjoy dedicated music playback anywhere.
Wireless Audio Setup
Source icon: SNOWSKY ECHOSource: Local Music LibraryConnection: BluetoothTarget icon: Bluetooth DeviceOutput: Wireless Audio System
Note: Connect with compatible Bluetooth devices.
USB DAC Setup
Source icon: ComputerSource: Digital MusicConnection: USBOutput connection: Headphone OutputTarget icon: HeadphonesOutput: USB DAC Audio System
Note: Use ECHO as an external audio device.
Technical Specifications
Audio
Feature
Specification
Product Type
Portable High-Resolution Music Player
DAC
High-Performance DAC System
Audio Playback
Lossless Music Playback
EQ
Supported
Outputs
Feature
Specification
3.5mm Output
Supported
4.4mm Balanced Output
Supported
USB DAC Output
Supported
Storage & Connectivity
Feature
Specification
microSD Expansion
Supported
Bluetooth
Supported
USB-C
Supported
Firmware Update
Supported
General
Feature
Specification
Product Type
Portable Music Player
Display
Color Display
Battery
Built-in Rechargeable Battery
Recommended System Setup
Setup
Connection
IEM Listening
ECHO → IEM
Portable Headphone
ECHO → Headphones
USB DAC Mode
Computer → ECHO → Headphones
Bluetooth System
ECHO → Wireless Device
What's in the box
SNOWSKY ECHO ×1
USB-C Cable ×1
Protective Accessories ×1
User Manual ×1
Download Center
Access product manuals, technical documents, and support resources.
https://emiuzek.com/pages/download
Additional Product Content
SNOWSKY Portable Player Comparison
Feature
ECHO
ECHO MINI
Product Position
Portable HiFi Music Player
Compact Entry-Level Music Player
Main Focus
Higher-performance portable audio
Small retro music player
Balanced Output
Yes
Yes
USB DAC
Yes
Yes
microSD Expansion
Yes
Yes
Best Focus
Portable HiFi enthusiasts
Simple everyday music playback
Description
FiiO FT1 Pro is an open-back planar magnetic HiFi headphone designed for listeners seeking high resolution, wide soundstage, and detailed musical reproduction.
Featuring a large 95×86mm planar driver, ultra-thin diaphragm, and lightweight open-back design, FT1 Pro delivers an immersive listening experience for desktop HiFi systems.
Why it stands out
Large Planar Magnetic Driver
FT1 Pro uses a FiiO-developed 95×86mm planar driver to deliver fast response, high resolution, and detailed sound reproduction.
Open-Back Sound Experience
The open-back design creates a spacious and natural listening experience with a wider soundstage.
Lightweight Planar Performance
The 374g lightweight construction provides a balance between planar magnetic performance and long listening comfort.
Balanced Connection Support
With detachable cable design and balanced 4.4mm compatibility, FT1 Pro works well with modern desktop DAC and headphone amplifier systems.
Best for
Desktop HiFi headphone systems
Audiophile music listening
DAC and headphone amplifier setups
Classical, jazz, vocal, and instrumental music
Users seeking wide soundstage headphones
Not ideal for
Noisy environments requiring strong isolation
Users needing wireless headphones
Users looking for active noise cancellation
Users wanting a compact portable headphone
EMiUZEK Buying Notes
FiiO FT1 Pro is an open-back planar magnetic headphone, not a wireless headphone.
The open-back design provides a wider soundstage but allows sound leakage.
For the best performance, pairing with a quality DAC and headphone amplifier is recommended.
Balanced 4.4mm output can provide better performance with compatible equipment.
FAQ
Is FiiO FT1 Pro a planar magnetic headphone?
Yes.
FT1 Pro uses a large planar magnetic driver developed by FiiO.
What is the difference between FT1 and FT1 Pro?
FT1 uses a closed-back dynamic driver design, while FT1 Pro uses an open-back planar magnetic design for higher resolution and wider soundstage.
Does FiiO FT1 Pro require a headphone amplifier?
It can work with many devices because of its 20Ω impedance, but a quality DAC/headphone amplifier can help achieve better performance.
Is FT1 Pro suitable for portable players?
Yes.
It can work with compatible portable players, especially devices with sufficient output power.
Does FT1 Pro support balanced connection?
Yes.
It supports balanced connection through a compatible 4.4mm cable.
Does FiiO FT1 Pro block outside noise?
No.
The open-back design prioritizes soundstage and natural listening rather than isolation.
Is FT1 Pro good for gaming?
Yes.
The open soundstage can provide an immersive experience, although it is mainly designed for music listening.
HOW TO CONNECT
Desktop HiFi Setup
Source icon: ComputerSource: High Resolution MusicConnection: USB DAC / Headphone AmplifierOutput connection: 4.4mm Balanced / 3.5mmTarget icon: FiiO FT1 ProOutput: High Resolution Headphone System
Note: Pair with desktop DAC and amplifier for maximum performance.
Portable Player Setup
Source icon: HiFi PlayerSource: Local Music FilesConnection: 3.5mm / 4.4mm OutputTarget icon: FiiO FT1 ProOutput: Portable HiFi Listening
Note: Suitable for compatible high-output portable players.
Technical Specifications
Headphone
Feature
Specification
Product Type
Open-Back Planar Magnetic Headphone
Driver Type
Planar Magnetic
Driver Size
95×86mm
Diaphragm Thickness
1μm
Design
Open-Back
Audio Performance
Feature
Specification
Frequency Response
7Hz–40kHz
Impedance
20Ω
Sensitivity
95dB/mW
Weight
Approx. 374g
Connectivity
Feature
Specification
Cable Connection
Detachable
Headphone Connector
Dual 3.5mm TRS
Plug Options
3.5mm / 4.4mm
Recommended System Setup
Setup
Connection
Desktop System
Computer → DAC → Headphone Amplifier → FT1 Pro
Portable System
HiFi Player → FT1 Pro
Balanced System
DAC/Amp 4.4mm Output → FT1 Pro
What's in the box
FiiO FT1 Pro Headphones ×1
3.5mm Cable ×1
4.4mm Balanced Cable ×1
Carrying Case ×1
Adapter ×1
User Manual ×1
Download Center
Access product manuals, technical documents, and support resources.
https://emiuzek.com/pages/download
Additional Product Content
FiiO FT Series Comparison
Feature
FT1
FT1 Pro
Product Type
Closed-Back Dynamic Headphone
Open-Back Planar Magnetic Headphone
Driver Type
Dynamic
Planar Magnetic
Sound Focus
Warm and immersive
Detailed and spacious
Isolation
Better
Lower
Best Use
Daily listening
Desktop HiFi listening
Description
SNOWSKY FiiO Wind PRO is a lightweight wireless on-ear headphone combining retro design with modern Bluetooth audio technology.
Featuring a 40mm high-fidelity dynamic driver, LDAC Bluetooth support, and long battery life, Wind PRO delivers a comfortable wireless listening experience for everyday music enjoyment.
Why it stands out
Retro Design with Modern Wireless Audio
Wind PRO combines classic on-ear headphone styling with modern Bluetooth connectivity for a unique everyday listening experience.
High-Quality Dynamic Sound
The 40mm dynamic driver delivers balanced sound with clear vocals, powerful bass, and enjoyable musical performance.
Lightweight Comfortable Design
The lightweight construction and adjustable headband provide comfortable wearing for long listening sessions.
Long Battery Life Wireless Listening
With extended battery performance and Bluetooth connectivity, Wind PRO is designed for convenient daily music playback.
Best for
Wireless music listening
Daily commuting
Smartphone users
Casual HiFi listening
Users who prefer lightweight headphones
Not ideal for
Users needing active noise cancellation
Professional studio monitoring
Users looking for wired audiophile headphones
Users needing a fully enclosed headphone design
EMiUZEK Buying Notes
SNOWSKY Wind PRO is a wireless Bluetooth headphone, not a wired-only headphone.
It uses an on-ear design, which provides a lighter and more portable wearing experience.
It does not include active noise cancellation.
LDAC performance depends on the connected Bluetooth device support.
FAQ
Does SNOWSKY Wind PRO support Bluetooth?
Yes.
Wind PRO supports Bluetooth wireless playback for smartphones, tablets, and other compatible devices.
Does SNOWSKY Wind PRO support LDAC?
Yes.
It supports high-resolution Bluetooth codecs including LDAC for compatible devices.
Does Wind PRO have active noise cancellation?
No.
Wind PRO focuses on lightweight design and sound quality rather than active noise cancellation.
What driver does SNOWSKY Wind PRO use?
It uses a 40mm high-fidelity dynamic driver.
Is SNOWSKY Wind PRO suitable for smartphones?
Yes.
It is designed for easy wireless connection with smartphones and portable devices.
How long can the battery last?
Wind PRO provides up to approximately 58 hours of battery life depending on usage conditions.
What is the difference between SNOWSKY Wind and Wind PRO?
Wind is a wired on-ear headphone, while Wind PRO adds Bluetooth wireless functionality and longer battery life.
HOW TO CONNECT
Bluetooth Smartphone Setup
Source icon: SmartphoneSource: Music StreamingConnection: BluetoothTarget icon: SNOWSKY Wind PROOutput: Wireless Music Listening
Note: Connect directly with smartphones, tablets, or laptops.
HiFi Portable Setup
Source icon: Portable PlayerSource: High Resolution MusicConnection: Bluetooth LDACTarget icon: SNOWSKY Wind PROOutput: Wireless HiFi Listening
Note: Use compatible devices for higher-quality Bluetooth playback.
Technical Specifications
Headphone
Feature
Specification
Product Type
Wireless On-Ear Headphone
Driver Type
Dynamic Driver
Driver Size
40mm
Design
On-Ear
Acoustic Design
Semi-Open
Bluetooth
Feature
Specification
Bluetooth Version
Bluetooth 5.3
Codec Support
LDAC / AAC / SBC
Wireless Range
Supported
Battery
Feature
Specification
Battery Life
Up to 58 hours
Charging
USB-C
General
Feature
Specification
Microphone
Built-in
Control
Button Control
Wearing Style
Adjustable Headband
Application
Music / Calls / Daily Use
Recommended System Setup
Setup
Connection
Smartphone Listening
Phone → Bluetooth → Wind PRO
Laptop Listening
Laptop → Bluetooth → Wind PRO
Portable Audio
Hi-Res Player → Bluetooth LDAC → Wind PRO
What's in the box
SNOWSKY Wind PRO ×1
USB-C Charging Cable ×1
User Manual ×1
Download Center
Access product manuals, technical documents, and support resources.
https://emiuzek.com/pages/download
Additional Product Content
SNOWSKY Wind vs Wind PRO
Feature
Wind
Wind PRO
Product Type
Wired On-Ear Headphone
Wireless On-Ear Headphone
Connection
3.5mm Cable
Bluetooth + Wireless
Driver
40mm Dynamic
40mm Dynamic
LDAC
No
Yes
Battery
No
Yes
Best Focus
Affordable wired listening
Wireless daily HiFi listening
Description
FiiO FT1 is a closed-back dynamic HiFi headphone designed to deliver detailed and immersive sound with a natural wooden design.
Featuring a large 60mm dynamic driver, nano wood fiber composite diaphragm, and comfortable over-ear closed-back structure, FT1 provides a balanced listening experience for both desktop and portable audio systems.
Why it stands out
Large 60mm Dynamic Driver
The custom-designed 60mm driver delivers powerful bass, detailed mids, and smooth high-frequency performance for a wide range of music genres.
Natural Wood Ear Cup Design
The real wood ear cups provide a premium appearance while contributing to the headphone's acoustic character.
Easy to Drive HiFi Performance
With a 32Ω impedance and high sensitivity design, FT1 works well with portable players, DACs, headphone amplifiers, and everyday audio devices.
Closed-Back Immersive Listening
The closed-back structure provides focused sound and improved isolation for personal listening environments.
Best for
Desktop HiFi headphone systems
Music listening at home
Portable players and DAC setups
Users wanting closed-back HiFi headphones
Rock, pop, jazz, and vocal music listening
Not ideal for
Users needing wireless Bluetooth headphones
Users looking for active noise cancellation
Users wanting an open-back wide soundstage experience
Professional studio monitoring requiring specialized tuning
EMiUZEK Buying Notes
FiiO FT1 is a wired closed-back headphone, not a wireless headphone.
It uses a detachable cable design and does not include built-in amplification.
The 32Ω impedance allows easier matching with portable players and desktop DAC/amps.
For the best performance, pairing with a quality DAC or headphone amplifier is recommended.
FAQ
Does FiiO FT1 require a headphone amplifier?
No.
FT1 can be driven by many portable players, computers, and mobile devices due to its low impedance and high sensitivity.
Is FiiO FT1 a closed-back headphone?
Yes.
The closed-back design helps provide better sound isolation and a more focused listening experience.
What driver does FiiO FT1 use?
FT1 uses a 60mm dynamic driver with a nano wood fiber composite diaphragm.
Is FiiO FT1 suitable for portable devices?
Yes.
Its 32Ω impedance and high sensitivity make it compatible with many portable audio sources.
Does FiiO FT1 support balanced connection?
Yes.
It uses detachable dual 3.5mm connectors and can be paired with compatible balanced cables.
What is the difference between FiiO FT1 and FT1 Pro?
FT1 uses a closed-back dynamic driver design, while FT1 Pro uses an open-back planar magnetic design with a different sound character.
Is FiiO FT1 suitable for gaming?
Yes.
The closed-back design provides good immersion, although it is primarily designed for music listening.
HOW TO CONNECT
Desktop HiFi Setup
Source icon: ComputerSource: High Resolution MusicConnection: USB DAC / Headphone AmplifierOutput connection: Headphone OutputTarget icon: FiiO FT1Output: Desktop Listening System
Note: Pair with DAC and headphone amplifier for improved performance.
Portable Audio Setup
Source icon: Portable Player / SmartphoneSource: Digital MusicConnection: Headphone OutputTarget icon: FiiO FT1Output: Portable HiFi Listening
Note: Enjoy high-quality wired listening on the go.
Balanced Audio Setup
Source icon: DAC / AmplifierSource: High Resolution MusicConnection: Balanced OutputTarget icon: FiiO FT1Output: Balanced Headphone System
Note: Use compatible balanced cables for optimized connections.
Technical Specifications
Headphone
Feature
Specification
Product Type
Closed-Back Dynamic Headphone
Driver Type
Dynamic Driver
Driver Size
60mm
Diaphragm
Nano Wood Fiber Composite
Ear Cup Material
Natural Wood
Audio Performance
Feature
Specification
Frequency Response
10Hz–40kHz
Impedance
32Ω
Sensitivity
98dB/mW
Sound Insulation
Approx. -26dB
Connectivity
Feature
Specification
Cable Connection
Detachable
Headphone Connector
Dual 3.5mm TRS
Cable Plug
3.5mm / 4.4mm
General
Feature
Specification
Weight
Approx. 340g (without cable)
Wearing Style
Over-Ear
Design
Closed-Back
Recommended System Setup
Setup
Connection
Portable System
Player → FT1
Desktop System
DAC/Amp → FT1
HiFi System
Computer → DAC → Headphone Amplifier → FT1
What's in the box
FiiO FT1 Headphones ×1
Detachable Cable ×1
Carrying Case ×1
Adapter ×1
User Manual ×1
Package Dimension: 226 × 224 × 127 mm (8.9 × 8.8 × 5 inch)
Gross Weight (Package): 0.99kg / 2.19lb
Download Center
Access product manuals, technical documents, and support resources.
https://emiuzek.com/pages/download
Additional Product Content
FiiO FT Series Comparison
Feature
FT1
FT1 Pro
Product Position
Closed-Back Dynamic Headphone
Open-Back Planar Headphone
Driver Type
Dynamic
Planar Magnetic
Design
Closed-Back
Open-Back
Main Focus
Bass response and isolation
Detail and wider soundstage
Best Use
Everyday HiFi listening
Audiophile desktop listening
Description
FiiO BR15 R2R is a high-resolution Bluetooth receiver and desktop DAC designed to upgrade modern and traditional HiFi systems.
Featuring a fully differential 24-bit R2R DAC, advanced Bluetooth decoding, USB DAC functionality, and balanced XLR/RCA outputs, BR15 R2R delivers flexible high-quality digital audio connectivity for home audio systems.
Why it stands out
True R2R DAC Architecture
BR15 R2R uses a fully differential R2R DAC design to deliver detailed and natural sound reproduction with high-resolution audio sources.
High-Quality Wireless Audio Upgrade
Advanced Bluetooth decoding with modern high-resolution codecs allows wireless music playback with excellent sound quality.
Flexible Digital Audio Hub
With USB, optical, coaxial, RCA, and XLR connectivity, BR15 R2R easily integrates into different HiFi systems.
Compact Desktop HiFi Solution
Its desktop design provides a simple way to add premium decoding and wireless capability to existing audio equipment.
Best for
Upgrading traditional amplifiers
Active speaker systems
Desktop HiFi setups
Bluetooth high-resolution audio systems
Users wanting R2R DAC performance
Not ideal for
Users needing a headphone amplifier
Users looking for a WiFi streaming player
Users requiring a speaker power amplifier
Users wanting a portable DAC solution
EMiUZEK Buying Notes
FiiO BR15 R2R is a Bluetooth receiver and DAC, not a power amplifier.
It cannot directly drive passive speakers.
Connect it to an amplifier, receiver, or powered speakers for audio playback.
For wireless playback, use compatible Bluetooth devices with supported codecs.
FAQ
Does FiiO BR15 R2R have a built-in headphone amplifier?
No.
BR15 R2R is mainly designed as a Bluetooth receiver and DAC with line-level outputs.
Can FiiO BR15 R2R connect to an amplifier?
Yes.
It can connect to amplifiers through RCA or balanced XLR outputs.
What DAC does FiiO BR15 R2R use?
It uses a fully differential 24-bit R2R DAC architecture designed by FiiO.
Does FiiO BR15 R2R support LDAC and aptX Lossless?
Yes.
It supports high-resolution Bluetooth codecs including LDAC and aptX Lossless.
Can FiiO BR15 R2R work with active speakers?
Yes.
The RCA and XLR outputs allow connection to compatible powered speakers.
Does FiiO BR15 R2R support USB DAC mode?
Yes.
It can be connected to computers through USB for high-resolution digital audio playback.
Does FiiO BR15 R2R support WiFi streaming?
No.
BR15 R2R focuses on Bluetooth, USB, optical, and coaxial audio input rather than network streaming.
HOW TO CONNECT
Bluetooth HiFi Upgrade
Source icon: SmartphoneSource: Bluetooth MusicConnection: BluetoothOutput connection: RCA / XLRTarget icon: Amplifier or Active SpeakersOutput: Wireless HiFi System
Note: Upgrade traditional audio systems with high-quality Bluetooth playback.
USB DAC Setup
Source icon: ComputerSource: High Resolution MusicConnection: USBOutput connection: RCA / XLRTarget icon: AmplifierOutput: Desktop HiFi System
Note: Use BR15 R2R as a desktop DAC.
Digital Audio Setup
Source icon: CD Player / TV / Digital SourceSource: Optical / CoaxialConnection: Digital InputOutput connection: Analog OutputTarget icon: AmplifierOutput: HiFi Audio System
Note: Add high-quality DAC conversion to digital sources.
Technical Specifications
DAC
Feature
Specification
DAC Architecture
Fully Differential 24-bit R2R
USB DAC Resolution
Up to 32-bit / 384kHz
DSD Support
Up to DSD256
PEQ
10-band Parametric EQ
Bluetooth
Feature
Specification
Bluetooth Chip
Qualcomm QCC5181
Bluetooth Version
Bluetooth 5.4/6.0 class chipset
LDAC
Supported
aptX Lossless
Supported
aptX Adaptive
Supported
AAC / SBC
Supported
Inputs
Feature
Specification
USB Audio Input
Supported
Optical Input
Supported
Coaxial Input
Supported
Bluetooth Input
Supported
Outputs
Feature
Specification
RCA Line Output
Supported
XLR Balanced Output
Supported
Optical Output
Supported
Coaxial Output
Supported
Recommended System Setup
Setup
Connection
Amplifier Upgrade
Phone → BR15 R2R → Amplifier → Speakers
Active Speaker System
Phone / PC → BR15 R2R → Active Speakers
Desktop DAC System
Computer → BR15 R2R → Amplifier → Speakers
What's in the box
FiiO BR15 R2R ×1
Power Cable ×1
USB Cable ×1
Remote Control ×1
User Manual ×1
Download Center
Access product manuals, technical documents, and support resources.
https://emiuzek.com/pages/download
Additional Product Content
FiiO BR15 R2R vs FiiO BR13
Feature
BR15 R2R
BR13
Product Position
R2R Bluetooth DAC
Bluetooth DAC Receiver
DAC Architecture
24-bit R2R
Traditional DAC
Bluetooth
High-resolution Bluetooth
Bluetooth Receiver
XLR Output
Yes
No
RCA Output
Yes
Yes
USB DAC
Yes
Limited
Best Focus
R2R sound + HiFi system upgrade
Affordable wireless upgrade
DescriptionAudio-Technica AT-VM750xSH is a premium dual moving magnet stereo cartridge with a nude Shibata stylus and solid boron cantilever.Its refined groove contact, rigid aluminum body, and high channel separation deliver detailed, dimensional vinyl playback with strong high-frequency retrieval.
Why it stands outNude Shibata StylusProvides a broad groove contact area for rich detail, extended high-frequency response, and reduced distortion.Solid Boron CantileverCombines low moving mass with high rigidity for responsive transient reproduction and precise signal transfer.Rigid Aluminum Cartridge BodyReduces unwanted vibration and resonance while providing effective shielding between channels.Interchangeable AT-VMx Stylus SystemAllows future replacement or sound-character upgrades using compatible stereo AT-VMx replacement styli.
Best for
Premium stereo vinyl systems
Listeners seeking rich detail and extended high-frequency response
Upgrading a compatible 1/2-inch-mount turntable
Carefully aligned tonearms with adjustable tracking force
Not ideal for
P-mount turntables
Turntables without an MM-compatible phono input or external MM phono stage
Users wanting a cartridge pre-mounted on a headshell
Systems that cannot be accurately aligned or set to the specified tracking force
EMiUZEK Buying Notes
AT-VM750xSH is a phono cartridge, not a complete headshell assembly.
It requires a compatible 1/2-inch mounting system and an MM phono input or external MM phono preamplifier.
Set tracking force to 1.8–2.2 g, with 2.0 g as the standard setting, and complete cartridge alignment before playback.
FAQDoes the AT-VM750xSH include a headshell?No. It is supplied as a cartridge for installation on a compatible headshell or headshell-integrated tonearm.What phono stage does it require?Use an MM-compatible phono input with a recommended load of 47 kΩ and 150–250 pF capacitance.Can it be used on a P-mount turntable?No. It is designed for compatible 1/2-inch mounting systems.What is the recommended tracking force?The specified range is 1.8–2.2 g, with 2.0 g as the standard setting.Which replacement stylus is the direct match?The direct replacement is the Audio-Technica AT-VMN50xSH, sold separately.Can other AT-VMx styli be installed?Compatible stereo AT-VMx replacement styli can be used for different stylus profiles and listening priorities; mono models are excluded.
HOW TO CONNECTStandard Turntable SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Cartridge PinsTarget icon: deviceOutput: MM Phono InputNote: Install and align the cartridge on a compatible 1/2-inch headshell or tonearm, then set the specified tracking force.External Phono Stage SetupSource icon: deviceSource: TurntableConnection: Tonearm WiringOutput connection: RCA Phono CableTarget icon: deviceOutput: External MM Phono StageNote: Connect the phono stage to an amplifier line input; do not connect the cartridge-level signal directly to a standard line input.
Technical SpecificationsCartridge
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–27,000 Hz
Output Voltage: 3.7 mV at 1 kHz, 5 cm/s
Channel Separation: 26 dB at 1 kHz
Output Balance: 1.0 dB at 1 kHz
Vertical Tracking Angle: 20°
Stylus and Tracking
Stylus: Nude Shibata
Stylus Curvature Radius: 2.7 × 0.26 mil
Cantilever: 0.28 mm solid boron
Tracking Force: 1.8–2.2 g; 2.0 g standard
Static Compliance: 20 × 10⁻⁶ cm/dyne
Dynamic Compliance: 7 × 10⁻⁶ cm/dyne at 100 Hz
Replacement Stylus: AT-VMN50xSH, sold separately
Electrical
Recommended Load Impedance: 47 kΩ
Recommended Load Capacitance: 150–250 pF
Coil Impedance: 3.2 kΩ at 1 kHz
DC Resistance: 750 Ω
Coil Inductance: 480 mH at 1 kHz
Physical
Mounting: 1/2-inch compatible
Threaded Holes: M2.6 × 2
Dimensions: 29.0 × 18.3 × 17.5 mm
Weight: 8.8 g
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the box
AT-VM750xSH cartridge
M2.6 cartridge installation screws: 10 mm × 2, 8 mm × 2, 5 mm × 2
Washers × 2
Non-magnetic screwdriver
Brush
Download CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica AT-VMx Cartridge Comparison
Feature
AT-VM750xSH
AT-VM740xML
AT-VM520xEB/H
Product Position
Premium Shibata cartridge
Premium MicroLinear cartridge
Pre-mounted elliptical cartridge and headshell
Stylus
Nude Shibata
Nude MicroLinear
Bonded elliptical
Cantilever
Solid boron
Tapered aluminum pipe
Aluminum pipe
Output Voltage
3.7 mV
3.2 mV
5.0 mV
Headshell Included
No
No
AT-LT10, pre-mounted
Best Use
Rich, detailed premium vinyl playback
Precise tracking and low inner-groove distortion
Convenient upgrade for compatible detachable-headshell tonearms
DescriptionAudio-Technica AT-VM740xML is a premium dual moving magnet stereo cartridge with a nude MicroLinear stylus and tapered aluminum-pipe cantilever.Its precise groove tracing, rigid aluminum body, and refined AT-VMx generator deliver detailed playback with excellent tracking and reduced inner-groove distortion.
Why it stands outNude MicroLinear StylusClosely follows complex groove modulations to retrieve fine detail and maintain clarity toward the inner grooves.Responsive AT-VMx GeneratorPCUHD coils and paratoroidal construction improve transient response, channel separation, and stereo definition.Rigid Aluminum Cartridge BodySuppresses unwanted resonance and vibration while providing effective electromagnetic shielding.Interchangeable AT-VMx Stylus SystemSupports compatible stereo AT-VMx replacement styli for future maintenance or a different stylus profile.
Best for
Detailed stereo vinyl playback
Reducing inner-groove distortion through precise setup
Upgrading a compatible 1/2-inch-mount turntable
Listeners who value tracking accuracy and clean high-frequency detail
Not ideal for
P-mount turntables
Turntables without an MM-compatible phono input or external MM phono stage
Users wanting a pre-mounted headshell assembly
Systems that cannot be accurately aligned or set to the specified tracking force
EMiUZEK Buying Notes
AT-VM740xML is a cartridge only; a headshell is not included.
It requires a compatible 1/2-inch mounting system and an MM phono input or external MM phono preamplifier.
Set tracking force to 1.8–2.2 g, with 2.0 g as the standard setting, and align overhang and cartridge geometry before use.
FAQDoes the AT-VM740xML include a headshell?No. It is supplied as a cartridge for installation on a compatible headshell or integrated tonearm.What phono stage does it require?Use an MM-compatible phono input with a recommended load of 47 kΩ and 150–250 pF capacitance.Can it be used on a P-mount turntable?No. It is designed for compatible 1/2-inch mounting systems.What is the recommended tracking force?The specified range is 1.8–2.2 g, with 2.0 g as the standard setting.Which replacement stylus is the direct match?The direct replacement is the Audio-Technica AT-VMN40xML, sold separately.Can other AT-VMx styli be installed?Compatible stereo AT-VMx replacement styli can be used for different stylus profiles and budgets; mono models are excluded.
HOW TO CONNECTStandard Turntable SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Cartridge PinsTarget icon: deviceOutput: MM Phono InputNote: Install and align the cartridge on a compatible 1/2-inch headshell or tonearm, then set the specified tracking force.External Phono Stage SetupSource icon: deviceSource: TurntableConnection: Tonearm WiringOutput connection: RCA Phono CableTarget icon: deviceOutput: External MM Phono StageNote: Connect the phono stage to an amplifier line input; do not connect the cartridge-level signal directly to a standard line input.
Technical SpecificationsCartridge
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–25,000 Hz
Output Voltage: 3.2 mV at 1 kHz, 5 cm/s
Channel Separation: 25 dB at 1 kHz
Output Balance: 1.0 dB at 1 kHz
Vertical Tracking Angle: 20°
Stylus and Tracking
Stylus: Nude MicroLinear
Stylus Curvature Radius: 2.2 × 0.12 mil
Cantilever: Tapered aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Static Compliance: 20 × 10⁻⁶ cm/dyne
Dynamic Compliance: 7 × 10⁻⁶ cm/dyne at 100 Hz
Replacement Stylus: AT-VMN40xML, sold separately
Electrical
Recommended Load Impedance: 47 kΩ
Recommended Load Capacitance: 150–250 pF
Coil Impedance: 3.2 kΩ at 1 kHz
DC Resistance: 750 Ω
Coil Inductance: 480 mH at 1 kHz
Physical
Mounting: 1/2-inch compatible
Threaded Holes: M2.6 × 2
Dimensions: 29.0 × 18.3 × 17.5 mm
Weight: 8.8 g
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the box
AT-VM740xML cartridge
M2.6 cartridge installation screws: 10 mm × 2, 8 mm × 2, 5 mm × 2
Washers × 2
Non-magnetic screwdriver
Brush
Download CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica AT-VMx Cartridge Comparison
Feature
AT-VM750xSH
AT-VM740xML
AT-VM520xEB/H
Product Position
Premium Shibata cartridge
Premium MicroLinear cartridge
Pre-mounted elliptical cartridge and headshell
Stylus
Nude Shibata
Nude MicroLinear
Bonded elliptical
Cantilever
Solid boron
Tapered aluminum pipe
Aluminum pipe
Output Voltage
3.7 mV
3.2 mV
5.0 mV
Headshell Included
No
No
AT-LT10, pre-mounted
Best Use
Rich, detailed premium vinyl playback
Precise tracking and low inner-groove distortion
Convenient upgrade for compatible detachable-headshell tonearms
DescriptionAudio-Technica AT-VM520xEB/H combines an AT-VM520xEB dual moving magnet cartridge with a bonded elliptical stylus, pre-mounted on an AT-LT10 universal headshell.It offers a convenient upgrade for compatible detachable-headshell tonearms, with factory assembly reducing installation work while retaining adjustable cartridge positioning.
Why it stands outPre-Mounted Cartridge and HeadshellCombines the cartridge and AT-LT10 headshell in one assembled package for faster installation on compatible tonearms.Bonded Elliptical StylusProvides more precise groove contact than a conical stylus for balanced detail and dependable everyday vinyl playback.Adjustable AT-LT10 HeadshellElongated through-holes allow cartridge positioning and overhang adjustment for correct turntable setup.Interchangeable AT-VMx Stylus SystemSupports compatible stereo AT-VMx replacement styli for maintenance or a future stylus-profile upgrade.
Best for
Compatible turntables with a detachable universal headshell
Users wanting a pre-mounted cartridge upgrade
Everyday stereo vinyl listening
Systems using an MM phono input
Not ideal for
Turntables with a fixed headshell or incompatible tonearm connector
P-mount turntables
Systems without an MM-compatible phono input or external MM phono stage
Users whose tonearm cannot accommodate the 18.3 g cartridge-and-headshell assembly
EMiUZEK Buying Notes
AT-VM520xEB/H includes the AT-VM520xEB cartridge pre-mounted on an AT-LT10 universal headshell; it is not the cartridge-only AT-VM520xEB package.
Verify tonearm connector compatibility, assembly weight, overhang, alignment, and tracking-force adjustment before purchase.
It requires an MM phono input or external MM phono preamplifier and cannot be connected directly to a standard amplifier line input.
FAQIs the cartridge already mounted on the headshell?Yes. The AT-VM520xEB cartridge is supplied pre-mounted on the AT-LT10 headshell, but final overhang, alignment, tracking force, and anti-skate checks are still required.Will it fit every turntable?No. It is intended for compatible tonearms that accept a detachable universal headshell. Check the tonearm connector and supported assembly weight.Can it be used on a P-mount turntable?No. It is not a P-mount cartridge assembly.What phono stage does it require?Use an MM-compatible phono input with a recommended load of 47 kΩ and 150–250 pF capacitance.What is the recommended tracking force?The specified range is 1.8–2.2 g, with 2.0 g as the standard setting.Which replacement stylus is the direct match?The direct replacement is the Audio-Technica AT-VMN20xEB, sold separately.
HOW TO CONNECTDetachable-Headshell Turntable SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Universal Headshell ConnectorTarget icon: deviceOutput: MM Phono InputNote: Install the headshell assembly on a compatible tonearm and verify overhang, alignment, tracking force, and anti-skate before playback.External Phono Stage SetupSource icon: deviceSource: TurntableConnection: Tonearm WiringOutput connection: RCA Phono CableTarget icon: deviceOutput: External MM Phono StageNote: Connect the phono stage to an amplifier line input; the cartridge-level signal is not intended for a standard line input.
Technical SpecificationsCartridge
Type: VM dual moving magnet stereo cartridge with headshell
Frequency Response: 20–23,000 Hz
Output Voltage: 5.0 mV at 1 kHz, 5 cm/s
Channel Separation: 24 dB at 1 kHz
Output Balance: 1.5 dB at 1 kHz
Vertical Tracking Angle: 20°
Stylus and Tracking
Stylus: Bonded elliptical
Stylus Size: 0.3 × 0.7 mil
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Static Compliance: 20 × 10⁻⁶ cm/dyne
Dynamic Compliance: 7 × 10⁻⁶ cm/dyne at 100 Hz
Replacement Stylus: AT-VMN20xEB, sold separately
Electrical
Recommended Load Impedance: 47 kΩ
Recommended Load Capacitance: 150–250 pF
Coil Impedance: 3.2 kΩ at 1 kHz
DC Resistance: 750 Ω
Coil Inductance: 480 mH at 1 kHz
Headshell Assembly
Headshell: AT-LT10
Compatible Cartridge Mount: Universal 1/2-inch, 4-pin cartridge mounting
Assembly Dimensions: 21.5 × 18.5 × 68.4 mm
Assembly Weight: 18.3 g
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the boxAT-VM520xEB cartridge pre-mounted on AT-LT10 headshellDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica AT-VMx Cartridge Comparison
Feature
AT-VM750xSH
AT-VM740xML
AT-VM520xEB/H
Product Position
Premium Shibata cartridge
Premium MicroLinear cartridge
Pre-mounted elliptical cartridge and headshell
Stylus
Nude Shibata
Nude MicroLinear
Bonded elliptical
Cantilever
Solid boron
Tapered aluminum pipe
Aluminum pipe
Output Voltage
3.7 mV
3.2 mV
5.0 mV
Headshell Included
No
No
AT-LT10, pre-mounted
Best Use
Rich, detailed premium vinyl playback
Precise tracking and low inner-groove distortion
Convenient upgrade for compatible detachable-headshell tonearms
DescriptionAudio-Technica AT-VM520xEB is a dual moving magnet stereo cartridge with a bonded elliptical stylus.Its updated AT-VMx generator, PCUHD coils, and elliptical profile provide balanced detail and dependable tracking for everyday HiFi vinyl systems.Why it stands outBonded Elliptical StylusProvides more precise groove contact than a conical stylus for balanced detail and reliable record playback.Updated AT-VMx GeneratorPCUHD coils and dual-magnet construction support responsive dynamics and clean stereo reproduction.Threaded Cartridge BodyM2.6 threaded inserts simplify installation on compatible through-hole headshells and tonearms.Interchangeable Stylus SystemAccepts compatible stereo AT-VMx replacement styli for maintenance or future upgrades.Best for
Everyday HiFi vinyl listening
Upgrading a compatible 1/2-inch-mount turntable
Listeners moving beyond a conical stylus
MM phono systems
Not ideal for
P-mount turntables
Users wanting a cartridge pre-mounted on a headshell
Systems without an MM phono input or external MM phono stage
EMiUZEK Buying Notes
AT-VM520xEB is a cartridge only; a headshell is not included.
It requires a compatible 1/2-inch mount and an MM phono input or external MM phono stage.
Set tracking force to 1.8–2.2 g, with 2.0 g standard, and complete cartridge alignment before use.
FAQDoes it include a headshell?No. This is the cartridge-only version.What phono stage does it require?Use an MM input with 47 kΩ load impedance and 150–250 pF load capacitance.Can it be used on a P-mount turntable?No. It is designed for compatible 1/2-inch mounting systems.What is the tracking force?1.8–2.2 g, with 2.0 g standard.What is the direct replacement stylus?AT-VMN20xEB, sold separately.Can other AT-VMx styli be used?Compatible stereo AT-VMx replacement styli can be used; mono models are excluded.HOW TO CONNECTStandard Turntable SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Cartridge PinsTarget icon: deviceOutput: MM Phono InputNote: Install and align the cartridge on a compatible 1/2-inch mount, then verify overhang, tracking force, and anti-skate.Technical SpecificationsCartridge and Stylus
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–23,000 Hz
Output Voltage: 5.0 mV at 1 kHz, 5 cm/s
Channel Separation: 24 dB at 1 kHz
Output Balance: 1.5 dB at 1 kHz
Stylus: Bonded elliptical, 0.3 × 0.7 mil
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Recommended Load: 47 kΩ / 150–250 pF
Replacement Stylus: AT-VMN20xEB
Weight: 7.2 g
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the box
AT-VM520xEB cartridge
M2.6 installation screws: 10 mm × 2, 8 mm × 2, 5 mm × 2
Washers × 2
Non-magnetic screwdriver
Brush
Download CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/download
DescriptionAudio-Technica AT-VMN95SH is a nude Shibata replacement stylus for compatible Audio-Technica VM95-series cartridge bodies.Rich, detailed vinyl playback, while restoring a worn compatible cartridge without replacing the complete cartridge body.Why it stands outnude Shibata ProfileProvides broad groove contact for rich detail and extended high-frequency retrieval.Direct VM95-Series ReplacementInstalls on compatible VM95 cartridge bodies without replacing the cartridge or rewiring the headshell.Interchangeable VM95 PlatformLets owners change stylus profile within the VM95 family while retaining the same compatible cartridge body.Best for
Replacing a worn stylus on a compatible VM95 cartridge
Rich, detailed vinyl playback
Users retaining an installed and aligned VM95 cartridge body
MM vinyl playback systems
Not ideal for
Non-VM95 cartridge bodies
Users needing a complete cartridge
Cartridge bodies with damage beyond the stylus assembly
EMiUZEK Buying Notes
AT-VMN95SH is a replacement stylus only; the cartridge body is sold separately.
Confirm the installed cartridge belongs to the Audio-Technica VM95 series before purchase.
After installation, use a tracking force of 1.8–2.2 g, with 2.0 g standard, and recheck setup.
FAQDoes this include the cartridge body?No. It is a replacement stylus assembly only.Which cartridges are compatible?It is designed for Audio-Technica VM95-series cartridge bodies.Does the cartridge need to be realigned?The cartridge body normally remains in place, but tracking force, anti-skate, and stylus seating should be checked after replacement.What tracking force should be used?1.8–2.2 g, with 2.0 g standard.How should it be installed?Remove the old stylus assembly carefully and seat the new assembly according to the Audio-Technica instructions without touching the cantilever or diamond tip.HOW TO CONNECTVM95 Stylus ReplacementSource icon: deviceSource: Compatible VM95 Cartridge BodyConnection: Replacement Stylus MountOutput connection: Cartridge PinsTarget icon: deviceOutput: MM Phono InputNote: Power off the system, replace the stylus carefully, and confirm tracking force and anti-skate before playback.Technical SpecificationsStylus
Product Type: Replacement stylus assembly
Stylus: nude Shibata
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Compatible Cartridge Body: Audio-Technica VM95 series
Recommended System Setup
Setup
Connection
VM95 Cartridge
AT-VMN95SH → Compatible VM95 Body → MM Phono Input
What's in the boxAT-VMN95SH replacement stylusDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentVM95 Replacement Stylus Comparison
Feature
AT-VMN95ML
AT-VMN95SH
Stylus
Nude MicroLinear
Nude Shibata
Best Use
Precise tracking and low inner-groove distortion
Rich detail and extended groove contact
Compatible Body
VM95 series
VM95 series
DescriptionAudio-Technica AT-VM95SH is a VM95-series dual moving magnet cartridge with a nude Shibata stylus.Its broad groove contact retrieves rich detail and extended high-frequency information for a refined vinyl upgrade.Why it stands outNude ShibataRich, detailed vinyl playback through a profile selected for accurate groove contact.VM95 Interchangeable Stylus PlatformSupports all six VM95-series replacement stylus assemblies for maintenance or future upgrades.Threaded Cartridge BodySimplifies installation on compatible 1/2-inch-mount headshells.Dual Moving Magnet DesignMirrors the cutter-head geometry for stable stereo separation and dependable playback.Best for
Rich, detailed vinyl playback
Compatible 1/2-inch-mount turntables
Users comfortable with cartridge alignment
MM phono systems
Not ideal for
P-mount turntables
Users wanting a pre-mounted headshell assembly
Systems without an MM phono input or external MM phono stage
EMiUZEK Buying Notes
AT-VM95SH is a cartridge only; a headshell is not included.
It requires installation and alignment on a compatible 1/2-inch mounting system.
Use an MM phono input and set tracking force to 1.8–2.2 g, with 2.0 g standard.
FAQDoes it include a headshell?No. A compatible headshell or tonearm mount is required.Will it fit every turntable?No. Verify 1/2-inch mounting and tonearm compatibility; it is not a P-mount product.What phono stage does it require?Use an MM-compatible phono input with 47 kΩ load impedance and 100–200 pF load capacitance.What is the tracking force?1.8–2.2 g, with 2.0 g standard.Can the stylus be replaced?Yes. The VM95 body accepts all six VM95-series replacement stylus assemblies.Is final setup still required?Yes. Cartridge alignment, overhang, tracking force, and anti-skate must be set correctly.HOW TO CONNECTStandard Turntable SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Cartridge PinsTarget icon: deviceOutput: MM Phono InputNote: Install and align the cartridge on a compatible 1/2-inch mount, then verify overhang, tracking force, and anti-skate.Technical SpecificationsCartridge and Stylus
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–25,000 Hz
Output Voltage: 3.5 mV at 1 kHz, 5 cm/s
Channel Separation: 23 dB at 1 kHz
Output Balance: 1.5 dB at 1 kHz
Stylus: Nude Shibata
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Electrical and Physical
Recommended Load: 47 kΩ / 100–200 pF
Cartridge Weight: 6.1 g
Cartridge Dimensions: 17.2 × 18.9 × 28.3 mm
Mounting: 1/2-inch compatible
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the boxAT-VM95SH cartridgeDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica VM95 Series Comparison
Feature
AT-VM95E
AT-VM95EN
AT-VM95ML
AT-VM95SH
Stylus
Bonded elliptical
Nude elliptical
Nude MicroLinear
Nude Shibata
Frequency Response
20–22,000 Hz
20–23,000 Hz
20–25,000 Hz
20–25,000 Hz
Best Use
Accessible everyday playback
Balanced detail upgrade
Precise tracking and low inner-groove distortion
Rich detail and extended groove contact
DescriptionAudio-Technica AT-VM95SH/H is an AT-VM95SH dual moving magnet cartridge with a nude Shibata stylus, pre-mounted on an AT-HS6 headshell.It combines rich Shibata groove retrieval with a ready-assembled format for compatible detachable-headshell tonearms.Why it stands outNude ShibataConvenient premium Shibata upgrade through a profile selected for accurate groove contact.VM95 Interchangeable Stylus PlatformSupports all six VM95-series replacement stylus assemblies for maintenance or future upgrades.Pre-Mounted AT-HS6 HeadshellReduces initial assembly work on compatible detachable-headshell tonearms.Dual Moving Magnet DesignMirrors the cutter-head geometry for stable stereo separation and dependable playback.Best for
Convenient premium Shibata upgrade
Compatible 1/2-inch-mount turntables
Detachable-headshell tonearms
MM phono systems
Not ideal for
P-mount turntables
Fixed-headshell or incompatible tonearms
Systems without an MM phono input or external MM phono stage
EMiUZEK Buying Notes
AT-VM95SH/H is a pre-mounted cartridge-and-headshell assembly.
Verify detachable-headshell connector compatibility and tonearm counterweight range before purchase.
Use an MM phono input and set tracking force to 1.8–2.2 g, with 2.0 g standard.
FAQDoes it include a headshell?Yes. The cartridge is pre-mounted on an AT-HS6 headshell.Will it fit every turntable?No. Verify 1/2-inch mounting and tonearm compatibility; it is not a P-mount product.What phono stage does it require?Use an MM-compatible phono input with 47 kΩ load impedance and 100–200 pF load capacitance.What is the tracking force?1.8–2.2 g, with 2.0 g standard.Can the stylus be replaced?Yes. The VM95 body accepts all six VM95-series replacement stylus assemblies.Is final setup still required?Yes. Check overhang, alignment, tracking force, and anti-skate after installation.HOW TO CONNECTDetachable-Headshell SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Universal Headshell ConnectorTarget icon: deviceOutput: MM Phono InputNote: Install the headshell on a compatible tonearm, then verify overhang, tracking force, and anti-skate.Technical SpecificationsCartridge and Stylus
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–25,000 Hz
Output Voltage: 3.5 mV at 1 kHz, 5 cm/s
Channel Separation: 23 dB at 1 kHz
Output Balance: 1.5 dB at 1 kHz
Stylus: Nude Shibata
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Electrical and Physical
Recommended Load: 47 kΩ / 100–200 pF
Cartridge Weight: 6.1 g
Cartridge Dimensions: 17.2 × 18.9 × 28.3 mm
Mounting: 1/2-inch compatible
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the boxAT-VM95SH cartridge pre-mounted on AT-HS6 headshellDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica VM95 Series Comparison
Feature
AT-VM95E
AT-VM95EN
AT-VM95ML
AT-VM95SH
Stylus
Bonded elliptical
Nude elliptical
Nude MicroLinear
Nude Shibata
Frequency Response
20–22,000 Hz
20–23,000 Hz
20–25,000 Hz
20–25,000 Hz
Best Use
Accessible everyday playback
Balanced detail upgrade
Precise tracking and low inner-groove distortion
Rich detail and extended groove contact
DescriptionAudio-Technica AT-VMN95ML is a nude MicroLinear replacement stylus for compatible Audio-Technica VM95-series cartridge bodies.Precise tracking and detailed playback, while restoring a worn compatible cartridge without replacing the complete cartridge body.Why it stands outnude MicroLinear ProfilePrecisely traces complex groove modulations for fine detail and reduced inner-groove distortion.Direct VM95-Series ReplacementInstalls on compatible VM95 cartridge bodies without replacing the cartridge or rewiring the headshell.Interchangeable VM95 PlatformLets owners change stylus profile within the VM95 family while retaining the same compatible cartridge body.Best for
Replacing a worn stylus on a compatible VM95 cartridge
Precise tracking and detailed playback
Users retaining an installed and aligned VM95 cartridge body
MM vinyl playback systems
Not ideal for
Non-VM95 cartridge bodies
Users needing a complete cartridge
Cartridge bodies with damage beyond the stylus assembly
EMiUZEK Buying Notes
AT-VMN95ML is a replacement stylus only; the cartridge body is sold separately.
Confirm the installed cartridge belongs to the Audio-Technica VM95 series before purchase.
After installation, use a tracking force of 1.8–2.2 g, with 2.0 g standard, and recheck setup.
FAQDoes this include the cartridge body?No. It is a replacement stylus assembly only.Which cartridges are compatible?It is designed for Audio-Technica VM95-series cartridge bodies.Does the cartridge need to be realigned?The cartridge body normally remains in place, but tracking force, anti-skate, and stylus seating should be checked after replacement.What tracking force should be used?1.8–2.2 g, with 2.0 g standard.How should it be installed?Remove the old stylus assembly carefully and seat the new assembly according to the Audio-Technica instructions without touching the cantilever or diamond tip.HOW TO CONNECTVM95 Stylus ReplacementSource icon: deviceSource: Compatible VM95 Cartridge BodyConnection: Replacement Stylus MountOutput connection: Cartridge PinsTarget icon: deviceOutput: MM Phono InputNote: Power off the system, replace the stylus carefully, and confirm tracking force and anti-skate before playback.Technical SpecificationsStylus
Product Type: Replacement stylus assembly
Stylus: nude MicroLinear
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Compatible Cartridge Body: Audio-Technica VM95 series
Approximate Stylus Life: approximately 1,000 hours
Recommended System Setup
Setup
Connection
VM95 Cartridge
AT-VMN95ML → Compatible VM95 Body → MM Phono Input
What's in the boxAT-VMN95ML replacement stylusDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentVM95 Replacement Stylus Comparison
Feature
AT-VMN95ML
AT-VMN95SH
Stylus
Nude MicroLinear
Nude Shibata
Best Use
Precise tracking and low inner-groove distortion
Rich detail and extended groove contact
Compatible Body
VM95 series
VM95 series
DescriptionAudio-Technica AT-VM95ML is a VM95-series dual moving magnet cartridge with a nude MicroLinear stylus.Its precise line-contact profile delivers excellent groove tracing, extended detail, and reduced inner-groove distortion.Why it stands outNude MicroLinearPrecise tracking and reduced inner-groove distortion through a profile selected for accurate groove contact.VM95 Interchangeable Stylus PlatformSupports all six VM95-series replacement stylus assemblies for maintenance or future upgrades.Threaded Cartridge BodySimplifies installation on compatible 1/2-inch-mount headshells.Dual Moving Magnet DesignMirrors the cutter-head geometry for stable stereo separation and dependable playback.Best for
Precise tracking and reduced inner-groove distortion
Compatible 1/2-inch-mount turntables
Users comfortable with cartridge alignment
MM phono systems
Not ideal for
P-mount turntables
Users wanting a pre-mounted headshell assembly
Systems without an MM phono input or external MM phono stage
EMiUZEK Buying Notes
AT-VM95ML is a cartridge only; a headshell is not included.
It requires installation and alignment on a compatible 1/2-inch mounting system.
Use an MM phono input and set tracking force to 1.8–2.2 g, with 2.0 g standard.
FAQDoes it include a headshell?No. A compatible headshell or tonearm mount is required.Will it fit every turntable?No. Verify 1/2-inch mounting and tonearm compatibility; it is not a P-mount product.What phono stage does it require?Use an MM-compatible phono input with 47 kΩ load impedance and 100–200 pF load capacitance.What is the tracking force?1.8–2.2 g, with 2.0 g standard.Can the stylus be replaced?Yes. The VM95 body accepts all six VM95-series replacement stylus assemblies.Is final setup still required?Yes. Cartridge alignment, overhang, tracking force, and anti-skate must be set correctly.HOW TO CONNECTStandard Turntable SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Cartridge PinsTarget icon: deviceOutput: MM Phono InputNote: Install and align the cartridge on a compatible 1/2-inch mount, then verify overhang, tracking force, and anti-skate.Technical SpecificationsCartridge and Stylus
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–25,000 Hz
Output Voltage: 3.5 mV at 1 kHz, 5 cm/s
Channel Separation: 23 dB at 1 kHz
Output Balance: 1.5 dB at 1 kHz
Stylus: Nude MicroLinear
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Electrical and Physical
Recommended Load: 47 kΩ / 100–200 pF
Cartridge Weight: 6.1 g
Cartridge Dimensions: 17.2 × 18.9 × 28.3 mm
Mounting: 1/2-inch compatible
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the boxAT-VM95ML cartridgeDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica VM95 Series Comparison
Feature
AT-VM95E
AT-VM95EN
AT-VM95ML
AT-VM95SH
Stylus
Bonded elliptical
Nude elliptical
Nude MicroLinear
Nude Shibata
Frequency Response
20–22,000 Hz
20–23,000 Hz
20–25,000 Hz
20–25,000 Hz
Best Use
Accessible everyday playback
Balanced detail upgrade
Precise tracking and low inner-groove distortion
Rich detail and extended groove contact
DescriptionAudio-Technica AT-VM95ML/H is an AT-VM95ML dual moving magnet cartridge with a nude MicroLinear stylus, pre-mounted on an AT-HS6 headshell.The assembled package combines precise groove tracing with convenient installation on compatible detachable-headshell tonearms.Why it stands outNude MicroLinearPrecise tracking and reduced inner-groove distortion through a profile selected for accurate groove contact.VM95 Interchangeable Stylus PlatformSupports all six VM95-series replacement stylus assemblies for maintenance or future upgrades.Pre-Mounted AT-HS6 HeadshellReduces initial assembly work on compatible detachable-headshell tonearms.Dual Moving Magnet DesignMirrors the cutter-head geometry for stable stereo separation and dependable playback.Best for
Precise tracking and reduced inner-groove distortion
Compatible 1/2-inch-mount turntables
Detachable-headshell tonearms
MM phono systems
Not ideal for
P-mount turntables
Fixed-headshell or incompatible tonearms
Systems without an MM phono input or external MM phono stage
EMiUZEK Buying Notes
AT-VM95ML/H is a pre-mounted cartridge-and-headshell assembly.
Verify detachable-headshell connector compatibility and tonearm counterweight range before purchase.
Use an MM phono input and set tracking force to 1.8–2.2 g, with 2.0 g standard.
FAQDoes it include a headshell?Yes. The cartridge is pre-mounted on an AT-HS6 headshell.Will it fit every turntable?No. Verify 1/2-inch mounting and tonearm compatibility; it is not a P-mount product.What phono stage does it require?Use an MM-compatible phono input with 47 kΩ load impedance and 100–200 pF load capacitance.What is the tracking force?1.8–2.2 g, with 2.0 g standard.Can the stylus be replaced?Yes. The VM95 body accepts all six VM95-series replacement stylus assemblies.Is final setup still required?Yes. Check overhang, alignment, tracking force, and anti-skate after installation.HOW TO CONNECTDetachable-Headshell SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Universal Headshell ConnectorTarget icon: deviceOutput: MM Phono InputNote: Install the headshell on a compatible tonearm, then verify overhang, tracking force, and anti-skate.Technical SpecificationsCartridge and Stylus
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–25,000 Hz
Output Voltage: 3.5 mV at 1 kHz, 5 cm/s
Channel Separation: 23 dB at 1 kHz
Output Balance: 1.5 dB at 1 kHz
Stylus: Nude MicroLinear
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Electrical and Physical
Recommended Load: 47 kΩ / 100–200 pF
Cartridge Weight: 6.1 g
Cartridge Dimensions: 17.2 × 18.9 × 28.3 mm
Mounting: 1/2-inch compatible
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the boxAT-VM95ML cartridge pre-mounted on AT-HS6 headshellDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica VM95 Series Comparison
Feature
AT-VM95E
AT-VM95EN
AT-VM95ML
AT-VM95SH
Stylus
Bonded elliptical
Nude elliptical
Nude MicroLinear
Nude Shibata
Frequency Response
20–22,000 Hz
20–23,000 Hz
20–25,000 Hz
20–25,000 Hz
Best Use
Accessible everyday playback
Balanced detail upgrade
Precise tracking and low inner-groove distortion
Rich detail and extended groove contact
DescriptionAudio-Technica AT-VM95EN is a VM95-series dual moving magnet cartridge with a nude elliptical stylus.Its lower-mass nude diamond improves clarity and transient detail while retaining the series' practical interchangeable-stylus design.Why it stands outNude ellipticalBalanced detail upgrade through a profile selected for accurate groove contact.VM95 Interchangeable Stylus PlatformSupports all six VM95-series replacement stylus assemblies for maintenance or future upgrades.Threaded Cartridge BodySimplifies installation on compatible 1/2-inch-mount headshells.Dual Moving Magnet DesignMirrors the cutter-head geometry for stable stereo separation and dependable playback.Best for
Balanced detail upgrade
Compatible 1/2-inch-mount turntables
Users comfortable with cartridge alignment
MM phono systems
Not ideal for
P-mount turntables
Users wanting a pre-mounted headshell assembly
Systems without an MM phono input or external MM phono stage
EMiUZEK Buying Notes
AT-VM95EN is a cartridge only; a headshell is not included.
It requires installation and alignment on a compatible 1/2-inch mounting system.
Use an MM phono input and set tracking force to 1.8–2.2 g, with 2.0 g standard.
FAQDoes it include a headshell?No. A compatible headshell or tonearm mount is required.Will it fit every turntable?No. Verify 1/2-inch mounting and tonearm compatibility; it is not a P-mount product.What phono stage does it require?Use an MM-compatible phono input with 47 kΩ load impedance and 100–200 pF load capacitance.What is the tracking force?1.8–2.2 g, with 2.0 g standard.Can the stylus be replaced?Yes. The VM95 body accepts all six VM95-series replacement stylus assemblies.Is final setup still required?Yes. Cartridge alignment, overhang, tracking force, and anti-skate must be set correctly.HOW TO CONNECTStandard Turntable SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Cartridge PinsTarget icon: deviceOutput: MM Phono InputNote: Install and align the cartridge on a compatible 1/2-inch mount, then verify overhang, tracking force, and anti-skate.Technical SpecificationsCartridge and Stylus
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–23,000 Hz
Output Voltage: 3.5 mV at 1 kHz, 5 cm/s
Channel Separation: 22 dB at 1 kHz
Output Balance: 2.0 dB at 1 kHz
Stylus: Nude elliptical
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Electrical and Physical
Recommended Load: 47 kΩ / 100–200 pF
Cartridge Weight: 6.1 g
Cartridge Dimensions: 17.2 × 18.9 × 28.3 mm
Mounting: 1/2-inch compatible
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the boxAT-VM95EN cartridgeDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica VM95 Series Comparison
Feature
AT-VM95E
AT-VM95EN
AT-VM95ML
AT-VM95SH
Stylus
Bonded elliptical
Nude elliptical
Nude MicroLinear
Nude Shibata
Frequency Response
20–22,000 Hz
20–23,000 Hz
20–25,000 Hz
20–25,000 Hz
Best Use
Accessible everyday playback
Balanced detail upgrade
Precise tracking and low inner-groove distortion
Rich detail and extended groove contact
DescriptionAudio-Technica AT-VM95E/H is an AT-VM95E dual moving magnet cartridge with a bonded elliptical stylus, pre-mounted on an AT-HS6 headshell.It provides an accessible, ready-assembled upgrade for compatible detachable-headshell turntables.Why it stands outBonded ellipticalAccessible everyday vinyl playback through a profile selected for accurate groove contact.VM95 Interchangeable Stylus PlatformSupports all six VM95-series replacement stylus assemblies for maintenance or future upgrades.Pre-Mounted AT-HS6 HeadshellReduces initial assembly work on compatible detachable-headshell tonearms.Dual Moving Magnet DesignMirrors the cutter-head geometry for stable stereo separation and dependable playback.Best for
Accessible everyday vinyl playback
Compatible 1/2-inch-mount turntables
Detachable-headshell tonearms
MM phono systems
Not ideal for
P-mount turntables
Fixed-headshell or incompatible tonearms
Systems without an MM phono input or external MM phono stage
EMiUZEK Buying Notes
AT-VM95E/H is a pre-mounted cartridge-and-headshell assembly.
Verify detachable-headshell connector compatibility and tonearm counterweight range before purchase.
Use an MM phono input and set tracking force to 1.8–2.2 g, with 2.0 g standard.
FAQDoes it include a headshell?Yes. The cartridge is pre-mounted on an AT-HS6 headshell.Will it fit every turntable?No. Verify 1/2-inch mounting and tonearm compatibility; it is not a P-mount product.What phono stage does it require?Use an MM-compatible phono input with 47 kΩ load impedance and 100–200 pF load capacitance.What is the tracking force?1.8–2.2 g, with 2.0 g standard.Can the stylus be replaced?Yes. The VM95 body accepts all six VM95-series replacement stylus assemblies.Is final setup still required?Yes. Check overhang, alignment, tracking force, and anti-skate after installation.HOW TO CONNECTDetachable-Headshell SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Universal Headshell ConnectorTarget icon: deviceOutput: MM Phono InputNote: Install the headshell on a compatible tonearm, then verify overhang, tracking force, and anti-skate.Technical SpecificationsCartridge and Stylus
Type: VM dual moving magnet stereo cartridge
Frequency Response: 20–22,000 Hz
Output Voltage: 4.0 mV at 1 kHz, 5 cm/s
Channel Separation: 20 dB at 1 kHz
Output Balance: 2.0 dB at 1 kHz
Stylus: Bonded elliptical
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Electrical and Physical
Recommended Load: 47 kΩ / 100–200 pF
Cartridge Weight: 6.1 g
Cartridge Dimensions: 17.2 × 18.9 × 28.3 mm
Mounting: 1/2-inch compatible
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the boxAT-VM95E cartridge pre-mounted on AT-HS6 headshellDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica VM95 Series Comparison
Feature
AT-VM95E
AT-VM95EN
AT-VM95ML
AT-VM95SH
Stylus
Bonded elliptical
Nude elliptical
Nude MicroLinear
Nude Shibata
Frequency Response
20–22,000 Hz
20–23,000 Hz
20–25,000 Hz
20–25,000 Hz
Best Use
Accessible everyday playback
Balanced detail upgrade
Precise tracking and low inner-groove distortion
Rich detail and extended groove contact
DescriptionAudio-Technica AT6180a is a combined stroboscopic speed-check disc and cartridge overhang guide for turntable setup.It helps verify 33⅓ and 45 rpm operation at 50 or 60 Hz and provides a reference for cartridge overhang adjustment.Why it stands out50/60 Hz Stroboscopic ScaleSupports turntable speed checking in different mains-frequency regions.33⅓ and 45 rpm ReferenceCovers the two principal LP and single playback speeds.Overhang Adjustment GuideAdds a cartridge setup reference in the same tool.Non-Electronic Setup DiscWorks as a visual calibration aid without batteries.Best for
Checking turntable speed
33⅓ and 45 rpm turntables
Cartridge overhang setup
Turntable maintenance and calibration
Not ideal for
78 rpm speed checking
Automatically correcting speed errors
Replacing a full cartridge alignment protractor for every tonearm geometry
EMiUZEK Buying Notes
AT6180a is a visual setup tool and does not adjust turntable speed automatically.
Read the correct 50 or 60 Hz scale under a suitable mains-referenced light source.
Follow the turntable or tonearm instructions when setting overhang.
FAQWhich speeds can it check?33⅓ and 45 rpm.Does it support both 50 and 60 Hz?Yes.Can it correct turntable speed?No. It only provides a visual reference.Does it replace every alignment protractor?No. Use the geometry specified by the turntable or tonearm manufacturer.HOW TO CONNECTSpeed CheckSource icon: deviceSource: Rotating Turntable PlatterConnection: Stroboscopic Disc Under Suitable LightOutput connection: Read Correct 50/60 Hz ScaleTarget icon: deviceOutput: Speed ReferenceNote: Select the scale matching the speed and local mains frequency.Overhang CheckSource icon: deviceSource: Mounted CartridgeConnection: Overhang GuideOutput connection: Adjust Cartridge PositionTarget icon: deviceOutput: Tonearm SetupNote: Follow the turntable or tonearm specification for the required overhang.Technical SpecificationsCalibration
Product Type: Stroboscopic disc and overhang guide
Speed Scales: 33⅓ rpm / 45 rpm
Frequency Scales: 50 Hz / 60 Hz
Additional Function: Cartridge overhang guide
Recommended System Setup
Setup
Connection
Speed Calibration
Platter → AT6180a → Suitable Light → Read Strobe Scale
Cartridge Setup
Headshell / Cartridge → Overhang Guide → Adjust Position
What's in the boxAT6180a stroboscopic disc and overhang guideDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/download
