Audio-Technica AT-VM520xEB/H combines an AT-VM520xEB dual moving magnet cartridge with a bonded elliptical stylus, pre-mounted on an AT-LT10 universal headshell.It offers a convenient upgrade for compatible detachable-headshell tonearms, with factory assembly reducing installation work while retaining adjustable cartridge positioning.
Why it stands outPre-Mounted Cartridge and HeadshellCombines the cartridge and AT-LT10 headshell in one assembled package for faster installation on compatible tonearms.Bonded Elliptical StylusProvides more precise groove contact than a conical stylus for balanced detail and dependable everyday vinyl playback.Adjustable AT-LT10 HeadshellElongated through-holes allow cartridge positioning and overhang adjustment for correct turntable setup.Interchangeable AT-VMx Stylus SystemSupports compatible stereo AT-VMx replacement styli for maintenance or a future stylus-profile upgrade.
Best for
Compatible turntables with a detachable universal headshell
Users wanting a pre-mounted cartridge upgrade
Everyday stereo vinyl listening
Systems using an MM phono input
Not ideal for
Turntables with a fixed headshell or incompatible tonearm connector
P-mount turntables
Systems without an MM-compatible phono input or external MM phono stage
Users whose tonearm cannot accommodate the 18.3 g cartridge-and-headshell assembly
EMiUZEK Buying Notes
AT-VM520xEB/H includes the AT-VM520xEB cartridge pre-mounted on an AT-LT10 universal headshell; it is not the cartridge-only AT-VM520xEB package.
Verify tonearm connector compatibility, assembly weight, overhang, alignment, and tracking-force adjustment before purchase.
It requires an MM phono input or external MM phono preamplifier and cannot be connected directly to a standard amplifier line input.
FAQIs the cartridge already mounted on the headshell?Yes. The AT-VM520xEB cartridge is supplied pre-mounted on the AT-LT10 headshell, but final overhang, alignment, tracking force, and anti-skate checks are still required.Will it fit every turntable?No. It is intended for compatible tonearms that accept a detachable universal headshell. Check the tonearm connector and supported assembly weight.Can it be used on a P-mount turntable?No. It is not a P-mount cartridge assembly.What phono stage does it require?Use an MM-compatible phono input with a recommended load of 47 kΩ and 150–250 pF capacitance.What is the recommended tracking force?The specified range is 1.8–2.2 g, with 2.0 g as the standard setting.Which replacement stylus is the direct match?The direct replacement is the Audio-Technica AT-VMN20xEB, sold separately.
HOW TO CONNECTDetachable-Headshell Turntable SetupSource icon: deviceSource: Vinyl RecordConnection: Stylus / GrooveOutput connection: Universal Headshell ConnectorTarget icon: deviceOutput: MM Phono InputNote: Install the headshell assembly on a compatible tonearm and verify overhang, alignment, tracking force, and anti-skate before playback.External Phono Stage SetupSource icon: deviceSource: TurntableConnection: Tonearm WiringOutput connection: RCA Phono CableTarget icon: deviceOutput: External MM Phono StageNote: Connect the phono stage to an amplifier line input; the cartridge-level signal is not intended for a standard line input.
Technical SpecificationsCartridge
Type: VM dual moving magnet stereo cartridge with headshell
Frequency Response: 20–23,000 Hz
Output Voltage: 5.0 mV at 1 kHz, 5 cm/s
Channel Separation: 24 dB at 1 kHz
Output Balance: 1.5 dB at 1 kHz
Vertical Tracking Angle: 20°
Stylus and Tracking
Stylus: Bonded elliptical
Stylus Size: 0.3 × 0.7 mil
Cantilever: Aluminum pipe
Tracking Force: 1.8–2.2 g; 2.0 g standard
Static Compliance: 20 × 10⁻⁶ cm/dyne
Dynamic Compliance: 7 × 10⁻⁶ cm/dyne at 100 Hz
Replacement Stylus: AT-VMN20xEB, sold separately
Electrical
Recommended Load Impedance: 47 kΩ
Recommended Load Capacitance: 150–250 pF
Coil Impedance: 3.2 kΩ at 1 kHz
DC Resistance: 750 Ω
Coil Inductance: 480 mH at 1 kHz
Headshell Assembly
Headshell: AT-LT10
Compatible Cartridge Mount: Universal 1/2-inch, 4-pin cartridge mounting
Assembly Dimensions: 21.5 × 18.5 × 68.4 mm
Assembly Weight: 18.3 g
Recommended System Setup
Setup
Connection
Integrated Amplifier
Turntable → MM Phono Input → Amplifier → Speakers
External Phono Stage
Turntable → MM Phono Stage → Line Input → Amplifier → Speakers
What's in the boxAT-VM520xEB cartridge pre-mounted on AT-LT10 headshellDownload CenterAccess product manuals, firmware updates, and additional support resources.https://emiuzek.com/pages/downloadAdditional Product ContentAudio-Technica AT-VMx Cartridge Comparison
Feature
AT-VM750xSH
AT-VM740xML
AT-VM520xEB/H
Product Position
Premium Shibata cartridge
Premium MicroLinear cartridge
Pre-mounted elliptical cartridge and headshell
Stylus
Nude Shibata
Nude MicroLinear
Bonded elliptical
Cantilever
Solid boron
Tapered aluminum pipe
Aluminum pipe
Output Voltage
3.7 mV
3.2 mV
5.0 mV
Headshell Included
No
No
AT-LT10, pre-mounted
Best Use
Rich, detailed premium vinyl playback
Precise tracking and low inner-groove distortion
Convenient upgrade for compatible detachable-headshell tonearms
